Rockchip OP1
64-bit SoC
Dual Display 4K & 2K
Onboard eMMC
Gigabit Ethernet
Rockchip OP1
64-bit processors with Arm® big.LITTLE technology
provide enhanced performance with low power consumption and high efficiency
A72
Dual Cortex™-A72 frequency 2.0GHz
A53
Quad Cortex™ A53 frequency 1.5GHz
GPU
Arm® Mali™ T860MP4
Arm® Mali™ T860MP4 GPU
Support OpenGL ES1.1 / 2.0 / 3.0 / 3.1 / 3.2, Vulkan 1.0, OpenCL1.1, 1.2, DX11 etc
FP32 Performance in GFLOPS
Flexible memory configurations
to meet your unique needs
RAM: 2 / 4 GB LPDDR4
Onboard eMMC: 16 / 32 / 64 / 128 GB
Immerse in 4K Delight, Exquisite Like Reality
Support H.265/VP9 (HEVC) hardware decode (up to 4Kp60)
Support H.264 hardware decode (up to 1080p60)
Supporting mirror and extended modes for display
Standard HDMI 2.0 up to 4k@60fps
MIPI DSI interface support 1080p@60fps
*HDMI and MIPI DSI can work at the same time, support mirror mode or extend modeMultiple Storage and Booting OS Solution
eMMC, Micro SD Card and M.2 M Key Connector
High Speed and Capacity to Fulfill Diverse Storage Needs
Micro SD Card
Supports up to 256 GB TF card
Onboard eMMC
Supports up to 128 GB
M.2 M Key
Supports up to 2TB M.2 M Key NVMe SSD
Various Accessories Support
Radxa Display 8 HD
Radxa ROCK Pi 23W PoE HAT
Radxa M.2 Extension Board
Radxa Penta SATA HAT
Raspberry Pi Camera
Module 2
Raspberry Pi 7" Touch Screen
Comprehensive Technical Documentation,
Active Community, and Extensive OS Support
Comprehensive Technical Documentation and Active Community!
Radxa provides comprehensive technical documentation, empowering users to fully utilize their products. At the same time, they actively maintain an engaged community, fostering communication and collaboration among users.
Extensive Open-Source OS Support
Experience comprehensive support for a diverse range of open-source operating systems on our SBCs. In addition to Radxa's backing, we actively collaborate with third-party OS organizations, providing you with an extensive selection of options. Empower your projects with exceptional versatility and innovation as you discover both Radxa and third-party supported OS choices here.
Additional Features
Camera
MIPI CSI 2 lanes via FPC connector
Support up to 800 MP camera
The Camera connector features a compact 1mm pitch
Headphone Jack
One 3.5mm audio jack (MIC input)
HD codec that supports up to 24-bit/96KHz audio
Gigabit Ethernet
GbE LAN without Power over Ethernet (PoE) support
USB 2.0
2x USB2 Host ports
USB 3.0
1x USB3 OTG port
1x USB3 HOST port
40x Color GPIO
Supporting various interface options:
2 x UART
2 x SPI bus
3 x I2C bus
1 x PCM/I2S
1 x SPDIF
2 x PWM
1 x ADC
6 x GPIO
2 x 5V DC power pin
2 x 3.3V power pin
Radxa ROCK 4A+
Global
This product is exclusively available through our network of Approved Partners. To find out more about our trusted partner network, please visit their websites.
ROCK 4A+ Works with
Radxa FPC Cable
7-inch Display or Camera Cable
Radxa Display 8 HD
An All-in-One Touchscreen Module
Radxa Power PD 30W
5A High Current Super Fast Charge
Radxa Camera 8M 219
IMX 219
Radxa Penta SATA HAT
A Complete NAS Solution
Radxa M.2 Extension Board
Easily Support M.2 SSD 2230/2242/2260/2280
Radxa Heatsink for ROCK 4
Specialized for ROCK 4 Series
