Radxa NX5 IO Board

an Application Board for Radxa NX5

product_name

Radxa NX5 with Radxa NX5 IO Board

Quick Functional Verification of 260Pin

Radxa NX5 Interface DiagramRadxa NX5 IO Board Interface Diagram

Interface Details

  • Video

    1x HDMI

    1x DP

    Video
  • USB

    4x USB3.0 HOST Port

    1x Micro USB 2.0 OTG Port

    USB
  • Storage

    1x MicroSD Card

    Storage
  • M.2 E Key Connector

    1x M.2 E Key Connector for Wi-Fi & BT

    M.2 E Key Connector
  • Ethernet

    1x Gigabit Ethernet with PoE Support

    Ethernet
  • Camera

    2x MIPI CSI

    Camera
  • Fan Header

    1x 2-Pin Fan Header

    Fan Header
  • Button

    1x Maskrom Button

    1x Power Button

    Button
  • Power

    1x 5V ONLY DC Power

    Power
  • 40-Pin GPIO

    I2S

    UART

    SPI

    PDM

    I2C

    PWM

    GPIO

    5V Power Out

    3.3V Power Out

    40-Pin GPIO
