Rockchip RK3308B
100M Ethernet
BT4
WiFi 4
Radxa ROCK Pi S
A Compact and Cost-Effective 1.7x1.7-inch Mini SBC
up to 1.0GHz
Versatile Memory and eMMC Configuration Choices
Optional DDR3 RAM: 256MB / 512MB
Optional Onboard eMMC: 0GB / 4GB / 8GB
Interface Details
Micro SD Card Slot
Utilized for Mass Storage and OS Boot
Optional Onboard eMMC
Maximize Storage and OS Boot Efficiency
eMMC 5.1 Compatibility
Optional OnBoard Wireless Module
Support WiFi4 and BT4 with an External Antenna Connector
100M Ethernet with PoE Support
One network cable supports power supply and networking
USB Ports
1x USB 2.0 HOST Type-A Port
1x USB 2.0 OTG Type-C Port for Power and Data
2x 26 User GPIO
Supporting various interface options4x I2C
3x PWM
2x SPI
3x UART
1x I2S
2x 5V DC power in
2x 3.3V DC power in
Comprehensive Technical Documentation and
Active Community
Comprehensive Technical Documentation and Active Community !
Radxa provides comprehensive technical documentation, empowering users to fully utilize their products. At the same time, they actively maintain an engaged community, fostering communication and collaboration among users.
