CM3S IO Board

an Application Board for Radxa CM3S(mEdge-RK3566)

Buy Now
CM3S IO Board

Radxa CM3S IO Board

Buy

Radxa CM3S with Radxa CM3S IO Board

Quick Functional Verification of 200 Pin

Radxa CM3S Interface Diagram Radxa CM3S IO Board Interface Diagram

Interface Details

  • Video

    1x MIPI DSI

    1x HDMI

  • Camera

    2x MIPI CSI

  • USB

    3x USB2.0 HOST Type A Ports

    1x Micro USB 2.0 OTG Port

  • SATA

    1x SATA 3.0 with PSU

  • Ethernet

    1x 100Mbit Ethernet with PoE support(Additional PoE HAT Required)

  • PCIe

    1x PCIe2.0

  • 40-Pin GPIO

    Supporting various interface options:

    I2S

    UART

    SPI

    PDM

    I2C

    PWM

    GPIO

    5V Power Out

    3.3V Power Out
