NX4 IO Board

Interface Details

• Video

  1x HDMI



• Camera

  2x MIPI CSI



• USB

  4x USB 3.2 Type-A Ports

  1x USB 3.2 Type-C Port



• Ethernet

  1x Gigabit Ethernet with PoE support(Additional PoE HAT Required)



• PCIe

  1x PCIe 2.0



• Storage

  1x M.2 M Key 2280 Slot



• 40-Pin GPIO

  I2S

  UART

  SPI

  I2C

  PWM

  GPIOs

  ......



• Other Interface

  1x FAN Header

  1x PoE Header

  1x RTC BAT Header

  1x PoE Backpower Header
