ROCK 4A

A Classic SBC with Dual Display and 4K

Buy Now

Radxa ROCK 4A

Rockchip RK3399
64-bit SoC
2GB / 4GB
Dual Display 4K & 2K
Gigabit Ethernet

Rockchip RK3399

Arm® big.LITTLE™ technology

Dual-Core Arm Cortex-A72

Up to 1.8GHz

Quad-Core Cortex-A53

Up to 1.4GHz

Arm® Mali™ T860MP4

Supports OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2,
DirectX11.1 etc

Arm® Mali™ T860MP4 GPU

Supports OpenGL ES1.1/2.0/3.0/3.1/3.2, OpenCL1.2,DirectX11.1 etc

FP32 Performance in GFLOPS

Experience the Charm of Dual Display and 4K

Support H.265/VP9 (HEVC) hardware decode (up to 4Kp60)

Support H.264 hardware decode (up to 1080p60)

Standard HDMI portssupport displays up to 4K@60fps

MIPI DSI interface Support 1080p@60fps

Experience the Charm of Dual Display and 4K

*HDMI and MIPI DSI can work at the same time, support mirror mode or extend mode.

Multiple Storage and Booting OS Solution
eMMC, Micro SD Card and M.2 M Key Connector

High Speed and Capacity to Fulfill Diverse Storage Needs

Micro SD Card

Supports up to 256 GB TF card

eMMC

Supports up to 128 GB

M.2 M Key

Supports up to 2TB M.2 M Key NVMe SSD

Various Accessories Support

Official Accessories:

Radxa Display 8 HD
Radxa ROCK Pi 23W PoE HAT
Radxa M.2 Extension Board
Radxa Penta SATA HAT

Third Party Accessories:

Raspberry Pi Camera
Module 2
Raspberry Pi 7" Touch Screen

Comprehensive Technical Documentation and
Active Community

Comprehensive Technical Documentation and Active Community !
Radxa provides comprehensive technical documentation, empowering users to fully utilize their products. At the same time, they actively maintain an engaged community, fostering communication and collaboration among users.

Additional Features

Camera
MIPI CSI 2 lanes via FPC connector
Support up to 800 MP camera
The Camera connector features a compact 1mm pitch
Headphone Jack
One 3.5mm audio jack (MIC input)
HD codec that supports up to 24-bit/96KHz audio
USB 2.0
2x USB2 Host ports
USB 3.0
1x USB3 OTG port
1x USB3 HOST port
Gigabit Ethernet
GbE LAN without Power over Ethernet (PoE) support
40-Pin GPIO Header
Supporting various interface options:
2 x UART
2 x SPI bus
3 x I2C bus
1 x PCM/I2S
1 x SPDIF
2 x PWM
1 x ADC
6 x GPIO
2 x 5V DC power pin
2 x 3.3V power pin

Attention:

The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
